DOWANOL DPM / RXSOL D-SOLV DPM

Description

RXSOL D-SOLV DPM glycol ether is a mid-to slow evaporating solvent. This hydrophilic solvent has 100% water solubility and is ideally suited as a coupling agent in a wide range of solvent systems. RXSOL D-SOLV DPM glycol ether has a higher flash point which making it easier to handle, store, and ship. Often incorporated into latex emulsion coatings RXSOL D-SOLV DPM glycol ether can be used to prevent shocking (coagulation of emulsion) when hydrophobic solvents are used. More broadly, its hydrophilic nature makes it an ideal coupling aid in water reducible coatings, and cleaning applications. RXSOL D-SOLV DPM glycol ether’s intermediate evaporation rate allow it to be used in a potentially wider range of systems than many other solvents.



















Technical Bulletin

RXSOL D-SOLV DPM
Dipropylene Glycol (Mono) Methyl Ether

CH₃O[CH₂CH(CH₃)O]₂H (One of several isomers)

Description

RXSOL D-SOLV DPM glycol ether is a mid-to slow evaporating solvent. This hydrophilic solvent has 100% water solubility and is ideally suited as a coupling agent in a wide range of solvent systems. RXSOL D-SOLV DPM glycol ether has a higher flash point which making it easier to handle, store, and ship. Often incorporated into latex emulsion coatings RXSOL D-SOLV DPM glycol ether can be used to prevent shocking (coagulation of emulsion) when hydrophobic solvents are used. More broadly, its hydrophilic nature makes it an ideal coupling aid in water reducible coatings, and cleaning applications. RXSOL D-SOLV DPM glycol ether’s intermediate evaporation rate allow it to be used in a potentially wider range of systems than many other solvents.

Physical and Chemical  Properties / Specification
Molecular weight (g/mol)		148.2
Boiling point @ 760 mmHg, 1.01 bar	374°F	190°C
Flash point (Setaflash Closed Cup)	167°F	75°C
Freezing point	-117°F	-83°C
Vapor pressure@ 20°C — extrapolated		0.28 mmHg 0.37 mbar
Specific gravity (25/25°C)		0.951
Density @ 20°C           @ 25°C	7.95 lb/gal 7.91 lb/gal	0.953 g/cm³ 0.948 g/cm³
Viscosity (cP or mPa•s @ 25°C)		3.7
Surface tension (dynes/cm or mN/m @ 25°C)		28.8
Specific heat (J/g/°C @ 25°C)		2.25
Heat of vaporization (J/g) at normal boiling point		267
Net heat of combustion (kJ/g) — predicted @ 25°C		27.2
Autoignition temperature	405°F	207°C
Evaporation rate	(n-butyl acetate = 1.0) (diethyl ether = 1.0)	0.035 351
Solubility, g/100 g @ 25°C    Solvent in water    Water in solvent		– –
Hansen solubility parameters (J/cm³)1/2    _d (Dispersion)    _p (Polar)    _h (Hydrogen bonding)		15.5 4.0 11.5
Flammable limits (vol.% in air)    Lower (measured @ 100°C)    Upper (measured @ 150°C)		1.10 14.00



Classification/Registry Numbers††
CAS Number	34590-94-8
AICS (Australia)	34590-94-8
DSL (Canada)	34590-94-8
ECL (Korea)	2-272
EINECS (EU)	252-104-2
MITI (Japan)	2-426
TSCA (U.S.)	34590-94-8
NOTE: Classifications apply only to this glycol ether product. It is the responsibility of the formulator to ensure that the final finished product complies with the regulations of a given country prior to its sale or distribution in that country.

Applications

• Coupling agent (often in blends) for water-based dilutable coatings.
• Active solvent for solvent-based coatings.
• Coupling agent and solvent in household and industrial cleaners, grease and paint removers, metal cleaners, and hard surface cleaners.
• Tail solvent for solvent-based gravure and flexographic printing inks.
• Primary solvent in solvent-based silk screen printing inks.
• Coupling agent in solvent blends for water-based gravure, flexographic, and silk screen printing inks.
• Coupling agent and solvent for vat dyeing fabrics.
• Mutual solvent, coupling agent, and emollient in cosmetic formulations.
• Stabilizer for agricultural herbicides.
• Coalescent for floor polishes and finishes

Features

• Powerful solvency
• Moderate evaporation rate
• Low viscosity
• High dilution ratio
• Low surface tension
• Coupling ability
• Wide range of applications

Handling ,Storage, and Safety



Handling

General Handling: Avoid breathing vapor. Use with adequate ventilation. Keep container closed.

Other Precautions: Containers, even those that have been emptied, can contain vapors. Do not cut,drill, grind, weld, or perform similar operations on or near empty containers. Spills of these organic materials on hot fibrous insulations may lead to lowering of the autoignition temperatures possibly resulting in spontaneous combustion.



Storage

Store in the following material(s): Carbon steel. Stainless steel. Phenolic lined steel drums. Do notstore in: Aluminum. Copper. Galvanized iron. Galvanized steel. information.

Storage Period:, Shelf life: Use within, Bulk 6 Months

Steel drums. 24 Months

Personal Protection

Eye/Face Protection: Use safety glasses.

Skin Protection: When prolonged or frequently repeated contact could occur, use protective clothing

chemically resistant to this material. Selection of specific items such as face shield, boots, apron, or full-body suit will depend on the task. Remove contaminated clothing immediately, wash skin area with soap and water, and launder clothing before reuse or dispose of properly.

Hand protection: Use gloves chemically resistant to this material when prolonged or frequently repeated contact could occur. Examples of preferred glove barrier materials include: Butyl rubber. Polyethylene/ethyl vinyl alcohol laminate (“PE/EVAL”). Examples of acceptable glove barrier materials include: Natural rubber (“latex”). Neoprene. Nitrile/butadiene rubber (“nitrile” or “NBR”). Polyvinyl chloride (“PVC” or “vinyl”). Viton.

NOTICE: The selection of a specific glove for a particular application and duration of use in a

workplace should also take into account all relevant workplace factors such as, but not limited to: Other chemicals which may be handled, physical requirements (cut/puncture protection, dexterity, thermal protection), potential body reactions to glove materials, as well as the instructions/specifications provided by the glove supplier.

Respiratory Protection: Atmospheric levels should be maintained below the exposure guideline. When respiratory protection is required for certain operations, use an approved air-purifying respirator.The following should be effective types of air-purifying respirators: Organic vapor cartridge.

Ingestion: Use good personal hygiene. Do not consume or store food in the work area. Wash hands

before smoking or eating.

Engineering Controls

Ventilation: Provide general and/or local exhaust ventilation to control airborne levels below the exposure guidelines.



Refer to MSDS before using the Product.

Label

RXSOL D-SOLV DPM glycol ether is a mid-to slow evaporating solvent. This hydrophilic solvent has 100% water solubility and is ideally suited as a coupling agent in a wide range of solvent systems. RXSOL D-SOLV DPM glycol ether has a higher flash point which making it easier to handle, store, and ship. Often incorporated into latex emulsion coatings RXSOL D-SOLV DPM glycol ether can be used to prevent shocking (coagulation of emulsion) when hydrophobic solvents are used. More broadly, its hydrophilic nature makes it an ideal coupling aid in water reducible coatings, and cleaning applications. RXSOL D-SOLV DPM glycol ether’s intermediate evaporation rate allow it to be used in a potentially wider range of systems than many other solvents.

LABEL PROPERTY

PRODUCT NAME : DOWANOLDPM
CAS number : 34590-94-8
UN number :
Formula : CH3OC3H6OC3H6OH
Odour :
Solubility in water : COMPLETE
Density : 0.950 at 25oC
Boiling point : 189 oC
Melting point : -80 oC
Viscosity : 3.5 cp at 25 oC
Flashpoint : 85 oC
