Description
It is blend of alkaline-based detergents, surfactants formulated with a strong foaming action designed to rapidly emulsify greasy soils and oxidation…thereby leaving coils dirt-free and shining. C-SHINE is recommended for cleaning air-cooled condensers, permanent filters and other finned heating and cooling coils.
Technical Bulletin
Alakaline Coil Cleaner & Britener
RXSOL-16-1668-025
Product Description:-
RXSOL-16-1668-025 non-acid coil cleaners developed to provide foaming and brightening capabilities comparable to acid-based coil cleaners…without the dangers of hydrofluoric acid. for cleaning of Air coolers, Scavenging air systems and turbochargers of diesel engine.
1> Excellent grease-cutting capability.
2> High foaming action-penetrates deep into multi-row coils to foam out dirt,grease and grime.
3> One step cleaner-cleans,brightens and deodorizes.
Procedure Of Use:-
In-service cleaning:-RXSOL-16-1668-025 is passes through the air trunking upstream of the charge aircooler, followed by a clean water rinse.For cleaning of air coolers, it is necessary to use correctly installed dosing and injection system.
Typical Cleaning Method :-
Dilute 1-3 parts water and apply with alow pressure sprayer. Leave on coils for 3-7 minutes then flush with water until all foam is removed. If use don built up roofsetc., it is important to make sure all residual cleaner is washed off roof surface after application. If good housekeeping practices are not followed, roof deterioration is possible. If used indoors, strong fumes may cause irritation to sensitive individuals evacuate area if necessary.
For cleaning of Air cooler and Air side of turbochargers, a solution of 5 – 25% RXSOL-16-1668-025 in fresh water is recommended. Inject the solution for 10-15minutes, then similar quantity of fresh water injected to rinse off emulsifieddeposits.
Handspray Cleaning:-
By Handspray,apply concentrate RXSOL-16-1668-025 all over the cooler coils. for good emulsificati -on & penetration. Allow the RXSOL-16-1668-025 for a minimum of 1 hour,then use a high pressu ure water to wash off the loosened deposits. During process always keep drain valve open. After satisfactory cleaning, and flushing through with fresh water, close air cooler drains. Note that during this process the engine must be stopped.
Soak method:-
Machine parts with stubborn carbon deposits to be cleaned is dipped into conc.Soln.of RXSOL-16-1668-025 then allow deposits to. Be broken down and loosened before removal, then rinse .
Precaution ::–
Avoid skin / eye contact. Wear gloves and goggles when using. Use in well ventilated areas. Donot breathe vapors.
PHYSICAL PROPERTIES ::–
APPEARANCE…..Clear Brownish Liquid
ODOR …..Fresh
pH …..13.50
SPECIFICGRAVITY…..1.25
Why RXSOL-16-1668-025 preferred by our CUSTOMER ?
⇔ Reduce air-conditioning cost by allowing air-conditioning systems and units to run at maximum efficiency , Saves energy costs
⇔ A proper regular maintenance program including the use can substantially lengthen condenser life and save equipment replacement and downtime.
⇔ Cuts quickly through oily grime and Industrial air-borne impurities to restore condenser coils.
⇔ Due to its high penetration effect , Agitation or Scrubbing doesn’t require
⇔ Simple spray on off operation to restores dirty condenser coils to peak efficiency
Characteristics:-
Formulated to remove oil,grease & carbon deposits from air coolers & scavenging system
Efficient and economical.
May be used for in-service cleaning.
Renders surfaces oil-repellent.
Maintains and stabilizes air cooler efficiency at maximum.
Saves time, maintenance costs and avoids risks of damage when dismantling.
Leaves no residue and has no harmful effect on engine.
Product in water solution is non-flammable, non-explosive and has no flash point.
Can be used for light carbon removal from machinery parts
**Read the Material Safety Data Sheet before using this product**
Label
It is blend of alkaline-based detergents, surfactants formulated with foaming action designed to rapidly emulsify greasy soils and oxidation…thereby leaving coils dirt-free and shining. C-SHINE is recommended for cleaning air-cooled condensers, permanent filters and other finned heating and cooling coils.
LABEL PROPERTY
Handspray Cleaning:-
By Handspray,apply concentrate RXSOL-16-1668-025 all over the cooler coils. for good emulsification & penetration. Allow the RXSOL-16-1668-025 for a minimum of 1 hour,then use a light water pressure to wash off the loosened deposits. During process always keep drain valve open. After satisfactory cleaning, and flushing through with fresh water, close air cooler drains. Note that during this process the engine must be stopped.
Soak method:-
Machine parts with stubborn carbon deposits to be cleaned is dipped into conc.Soln.of RXSOL-16-1668-025 then allow deposits tobe broken down and loosened before removal, then rinse .
Precaution ::–
Avoid skin / eye contact. Wear gloves and goggles when using. Use in well ventilated areas. Donot breathe vapours.
