Technical Bulletin
Description: Butyl Diglycol
|
Test Description |
Specification Limits Min. Max. |
Unit of Measure |
Test Method |
||||
|
Butyl Diglycol |
99.0 |
%(w/w) |
Gas Chromatography |
||||
|
Water |
0.10 |
%(w/w) |
ASTM E-203 |
||||
|
Acidity as Acetic acid |
0.005 |
%(w/w) |
ASTM D-1613 |
||||
|
Colour, PTCO |
10 |
ASTM D-1209 |
|||||
|
Specific Gravity |
0.9005 |
0.9040 |
ASTM D-4052 |
||||
|
Appearance, P/F |
Clear, Clean Liquid |
ASTM D-2090 |
|||||
|
Density 20oC |
0.950 |
0.953 |
Kg/l |
||||
Label
General Information
Form ………………………………………………………………………………… Fluid
Colour ………………………………………………………………………………. Colourless
Odour ……………………………………………………………………………….. Characteristic
Change in condition
Melting point/Melting range ……………………………………………………… -68°C
Boiling point/Boiling range ………………………………………………………. 224 – 234°C
Flash point ………………………………………………………………………….. 98°C
Ignition temperature ……………………………………………………………….. 225°C
Danger of explosion ……………………………………………………………….. Product does not present an explosion hazard.
Explosion limits:
Lower …………………………………………………………………………………. 0.9 Vol %
Upper …………………………………………………………………………………. 5.9 Vol %
Vapour pressure at 20°C …………………………………………………………. 0.1 hPa
Density at 20°C …………………………………………………………………….. 0.95 g/cm³
Solubility in / Miscibility with water. ……………………………………………. Fully miscible.
Viscosity:
Dynamic at 22°C ……………………………………………………………………. 6.16 mPas
LABEL PROPERTY
